The TP-Link TL-SG2210MP is a smart switch designed for professional environments requiring high efficiency and flexibility in their networks. It features 10 total ports, of which 8 are Gigabit Ethernet RJ-45 ports with PoE+ support, allowing devices such as IP cameras, VoIP phones, or wireless access points to be powered directly through the network cable, simplifying infrastructure and reducing installation costs. Its black color and compact design provide a robust and visually discreet solution for offices or data centers. This switch supports advanced network standards such as IEEE 802.1D, 802.1Q, 802.1p, 802.1s, 802.1w, 802.1x, and 802.3ab, ensuring optimal management capabilities with features like VLANs, Quality of Service (QoS), port security, and link aggregation, enabling efficient and secure traffic administration. Its 20 Gbit/s switching capacity and support for up to 8000 MAC address table entries guarantee stable and scalable performance for data-intensive networks. It operates on 220 V power with multivoltage support, offering versatility in different electrical environments. The combination of its 8 Gigabit PoE+ ports and 2 additional uplink ports makes it an ideal solution for small and medium businesses needing to connect multiple devices securely and efficiently, improving bandwidth management and distribution. In short, the TP-Link TL-SG2210MP is a smart switch with PoE+ functionality that delivers the robustness, management capacity, and connectivity required to optimize professional network infrastructures with a balance of performance and practicality.

• Power supply: 150 W
• Approx. dimensions: 29,4 x 18 x 4,4 cm
• Recommended use: Rack Cabinet
• Certificate:
  • CE & RoHS, FCC
  • CE, FCC, RoHS
• Ventilator:
  • x 1
  • 1
• Connections:
  • Ethernet LAN
  • rj45 x 8
• Ports:
  • 8
  • 10
• Product with plug: Yes
• Type of plug: Plug EU
• Type:
  • Switch
  • Tablecloth
• Speed: 1 Gbps
• Colour: Black
• Year: 2018
• Holder: Multi-support
• Voltage: 220 V
• Power: 150 W
• Weight: 1,2 kg
• Working range for humidity: 10 % - 90 %
• Approx. temperature: -40º / 70º

Realize More Possibilities with OmadaJetStream 10-Port Gigabit Smart Switch with 8-Port PoE+Software Defined Networking (SDN) with Cloud AccessOmada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

• Quality of Service (QoS) support: Y
• Web-based management: Y
• Cloud-managed: Y
• System event log: Y
• MIB support: RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1213, RFC2233, RFC1643, RFC1493
• Basic switching RJ-45 Ethernet ports quantity: 8
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• Fiber ports quantity: 2
• Fiber optic connector: SFP
• Networking standards: IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
• 10G support: N
• Copper ethernet cabling technology: 10BASE-T,100BASE-TX
• Port mirroring: Y
• Flow control support: Y
• Link aggregation: Y
• Broadcast storm control: Y
• Rate limiting: Y
• Auto MDI/MDI-X: Y
• Auto-negotiation: Y
• VLAN support: Y
• Virtual LAN features: MAC address-based VLAN,Protocol-based VLAN,Tagged VLAN,Voice VLAN
• Number of VLANs: 4000
• Fiber ethernet cabling technology: 100BASE-FX,1000BASE-X
• MAC address table: 8000 entries
• Switching capacity: 20 Gbit/s
• Forwarding rate: 14.9 Mpps
• Number of queues: 8
• Jumbo frames support: Y
• Jumbo frames: 9000
• Packet buffer memory: 0.5 MB
• DHCP features: DHCP snooping,DHCPv6 snooping
• Access Control List (ACL): Y
• Security algorithms: EAP-LEAP,EAP-MD5,EAP-TLS,EAP-TTLS,HTTPS,SNMP,SNMPv2,SNMPv3,SSH,SSH-2,SSL/TLS
• Queue scheduling algorithms: SP, Weighted Round Robin (WRR)
• Multicast support: Y
• Product colour: Black
• Number of fans: 1 fan(s)
• Certification: CE, FCC, RoHS
• Power over Ethernet (PoE): Y
• Power over Ethernet (PoE) ports quantity: 8
• Total Power over Ethernet (PoE) budget: 150 W
• Operating temperature (T-T): 0 - 50 °C
• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 10 - 90%
• Storage relative humidity (H-H): 5 - 90%
• Width: 294 mm
• Depth: 180 mm
• Height: 44 mm
